| Material |
Galvanized, Prepainted Steel
Grades D (50 KSI Min.) & E (80 KSI Min.) |
| Thickness |
26 - 29 Gauge (.018” - .015”) |
| Speed |
100 FPM, Single Speed |
| Cut Lengths |
2’ Minimum, 21’ Maximum |
| Blank Width – Double Hem |
38” Maximum Part with ½” Double Hem – 39” Strip Width
5” Minimum Part with ¼” Double Hem - 5 ½” Strip Width |
| Blank Width – Single Hem |
35 ¼” Maximum part with ½” Single Hem – 35 ¾” Strip Width
3” Minimum Part with ¼” Single Hem – 3 ¼” Strip Width
|
| Passline |
38-3/8” |
| Main |
115 Volt, Single Phase, 60HZ |
